Official CMS IntelliCAD 7.1 released

Tweet

November 25th, 2011 - Burleson, Texas, USA. CAD Manufacturing Solutions, Inc. (CMS) announces CMS IntelliCAD® 7.1

IntelliCAD Technology Consortium (ITC) has recently announced the release of  IntelliCAD® 7.1 CAD Software.

IntelliCAD 7.1 is a maintenance release that contains many improvements since the IntelliCAD 7.0 release in August, while also including performance enhancements throughout in areas such as printing, zooming, multiline text, and .pdf file export. IntelliCAD 7.1 also supports new features: attach .dgn files, drag-and-drop layouts between drawings, invert image clips (raster image support is available in Professional versions), and more.

IntelliCAD 7.1 integrates Open Design Alliance Teigha® version 3.4.1 released earlier this year.

CMS, Inc., a strongly committed ITC commercial member, has just released it.

Both extremely affordable and flexible, CMS IntelliCAD® 7.1 provides a CAD toolkit for architects, engineers, and consultants that is compatible with Autodesk® AutoCAD®.

It easily helps you also to migrate your LISP, ARX, DRX, SDS or ADS applications, and includes a full built-in  Microsoft® VSTA or VBA IntelliCAD® programming environment. IntelliCAD® 7.1 is the alternative CAD programming platform developers were waiting for.

CMS, Inc., provides stand alone, dual, multiple-user, network and cloud licensing options.

Download it now here >

CMS IntelliCAD® 7.1. "Always the latest and most advanced version with CMS, Inc."

TRADEMARKS. IntelliCAD and the IntelliCAD logo are registered trademarks of the IntelliCAD Technology Consortium in the United States and other countries. All other trademarks are property of the respective owners. DWG is the native file format for Autodesk® AutoCAD® software and is a trademark of Autodesk, Inc.
IntelliCAD Technology Consortium and CAD Manufacturing Solutions, Inc. are not affiliated with Autodesk, Inc.

Official CMS IntelliCAD 7 released

Tweet

July 14th, 2011 - Burleson, Texas, USA. IntelliCAD Technology Consortium and CMS, Inc. announces CMS IntelliCAD® 7.

IntelliCAD Technology Consortium (ITC) has recently announced the release of  IntelliCAD® 7 CAD Software. A complete, new architecture based on and synchronized with the development platform from the Open Design Alliance.

IntelliCAD® 7 provides compatibility with Autodesk® DWG™ format and also exposes a powerful development environment with new support for custom objects.

CAD Manufacturing Solutions, Inc., a strongly committed ITC commercial member, has also just released this new and amazing CAD technology into the market.

Both extremely affordable and flexible, CMS IntelliCAD® 7 provides a CAD toolkit for architects, engineers, and consultants that is compatible with Autodesk® AutoCAD®.

It easily helps you also to migrate your LISP, ARX, DRX, SDS or ADS applications, and includes a full built-in new Microsoft® VSTA IntelliCAD® programming environment. IntelliCAD® 7 is the NEW and alternative CAD programming platform developers were waiting for.

Download it now here >

CMS IntelliCAD® 7. All in One. Enjoy and Get Involved!



TRADEMARKS. IntelliCAD and the IntelliCAD logo are registered trademarks of the IntelliCAD Technology Consortium in the United States and other countries. All other trademarks are property of the respective owners. DWG is the native file format for Autodesk® AutoCAD® software and is a trademark of Autodesk, Inc.
IntelliCAD Technology Consortium and CAD Manufacturing Solutions, Inc. are not affiliated with Autodesk, Inc.

Run CMS IntelliCAD from Cloud

Tweet

February 21th, 2011 - Burleson, Texas, USA. CMS, Inc. announces CMS IntelliCAD Cloud licensing availability.

 CAD Manufacturing Solutions, Inc., the developers of CMS IntelliCAD CAD software and Code Systems Corporation dba Spoon, Inc., a pioneer in application virtualization and cloud computing technologies, announced the availability of CMS IntelliCAD® Standard Cloud license, a professional full-featured CAD software programing toolkit, using Cloud-Virtualization Computing.

Both affordable and flexible, CMS IntelliCAD provides a CAD toolkit for architects, engineers, and consultants that is compatible with Autodesk AutoCAD, LISP, ADS, built-in Microsoft VBA 6.4., and programmable with hundreds of other third-party solutions. Features include a full suite of 2D and 3D drawing tools, easy visual customization of menus and toolbars, the ability to open multiple drawings at once, the IntelliCAD Drawing Explorer™ for simple drag-and-drop viewing of content, and ActiveX integration that lets you include design segments or entire drawings in Microsoft Office and OpenOffice files.



Key Advantages:

a) No licensing issues -  CMS IntelliCAD Cloud license will run from any MS Windows machine with a working internet connection (not simultaneously); License managment is no longer required, signing in to the internet server is enough to run CMS IntelliCAD on Cloud.

b) Keep full cad files availability, and property - No end user file upload is required. CAD files are kept on local end user storage system as they have always been.

c) Speed & Performance - Streaming CMS IntelliCAD from the Cloud does not introduce any performance degradation, in fact it loads faster (on regular use) than the traditional local install.



A end user can now try-or-buy a CMS IntelliCAD Cloud license from http://spoon.net/intellicad

* SHARE* You can also add a launch button for our app to your web site by copying and pasting the HTML code available on the above link.

TRADEMARKS. IntelliCAD and the IntelliCAD logo are registered trademarks of the IntelliCAD Technology Consortium in the United States and other countries. All other trademarks are property of the respective owners. DWG is the native file format for Autodesk® AutoCAD® software and is a trademark of Autodesk, Inc.
IntelliCAD Technology Consortium and CMS, Inc. are not affiliated with Autodesk, Inc.

CMS IntelliCAD 7 Public Beta Testers registration program has started

Tweet

January 4th, 2011 - Burleson, Texas, USA. CMS, Inc announces CMS IntelliCAD 7 Public Beta Testers registration program.

The objective of CMS IntelliCAD Beta Program is to gain customer feedback on IntelliCAD products. IntelliCAD 7 public beta software will be also available to 100 CMS IntelliCAD website registered users interested in testing official IntelliCAD software and providing feedback to IntelliCAD Technology Consortium (ITC) product & engineering teams.

Why Participate:

• Exposure to next-generation features helps you grow your technical skills;
• Ability to prove that the product will work properly in your environment, and report areas where it does not;
• Prototype your solution during the beta program and be ready for deployment when we reach General Availability;

What is included:

• Access to the official IntelliCAD 7 Beta software;
• Ability to log issues and feature requests;

CMS Program is now open for registration exclusively for all previous CMS IntelliCAD website registered users.  ITC will manage this Public Beta testing program.

CMS IntelliCAD CAD Software Cloud Application Streaming

Tweet

August 19th, 2010 - Bryant, Arkansas, USA. CMS, Inc. has just introduced the latest and most advanced application streaming technology into the CAD industry. We are probably the first CAD company widely providing this technology.

You can now quickly load and seamlessly run CMS IntelliCAD STD directly from our website domain, without the need to install it, and without any significant performance degradation.

We believe that common cloud technology, i.e., typically running a software inside a browser window, has some important barriers still difficult to crossover, specially with CAD applications. Manly they are internet connection speed and performance, file security and availability.

With the technology we are now providing, you are basically downloading key portions of our software that enables it to start running, and remaining features are loaded only when required. At the moment, we are just allowing our software to be loaded from our website, but it's already prepared for offline mode, i.e., IntelliCAD stream will be hosted on your drive or any mobile drive. Always without needing to install our software.

You will always keep your files where they have always been. Contrary to the standard cloud technology concept, with CMS IntelliCAD and Cloud Streaming technology you will never need to upload your files to a cloud server, and so you will have them always available and secured!

That's right, you can even run it from here!

Feel free to run and try it now! Click on the green start button.

CMS IntelliCAD cloud application streaming from CMS, Inc. on Vimeo.

CMS IntelliConvert - The DWG, DXF File version converter

It's common to see customers willing to have the ability to batch convert DWG files between different versions. Or even convert a recent DWG file version into an old version they are able to open or edit using their own cad software.

We have just added new product to our catalog. CMS IntelliConvert supports these required features:

• Easy to use Stand-alone application - No other software is required.
• Converts DWG to DXF, and DXF to DWG files. Batch conversion is supported.
• DWG/DXF file version converter.
• Supports the most common DWG/DXF file versions (R12 to V2010-2011 DWG/DXF file formats).

This software tool can be downloaded and used for trial purposes. It's freely included with new CMS IntelliCAD 6.6 purchases, or purchased separately for $51.95

DWG is a Autodesk trademark, and it's referred here as file extension that CMS IntelliConvert is able to process.

New CMS IntelliCAD v6.6 build CAD software release! We have updated v6.6 again, and you are able to get the latest IntelliCAD 100% compliant code with CMS IntelliCAD 6.6.82.0.

Free trial available at http://intellicadms.com

Upgrade from any CAD software

April 12, 2009 - Bryant, Arkansas  -  CAD Manufacturing Solutions, the developers of CMS IntelliCAD CAD software, today announced the availability of CMS IntelliCAD 6.6 PRO Upgrade from any CAD Software edition, the latest version of the full featured and powerful official IntelliCAD Software.

If you are looking for upgrading your CAD Software, whatever it may be, then CMS IntelliCAD may be your choice.

CMS IntelliCAD 6.6 PRO is a Reliable, Affordable, Powerful and Responsive CAD application, that will allow you to upgrade your drafting and drawing tools to a full set of advanced features.

CMS IntelliCAD 6.6 PRO - Professional Edition.

This release includes a full featured set of 2D & 3D CAD tools also included in the Standard edition, plus ACIS Solid Modeling, Rendering and Lighting, advanced Raster control, VBA and Lisp programming.

Why should you upgrade to CMS IntelliCAD? our customers have your answer.

"You have been one of the most responsive software companies I've worked with in a long time."
Steven Schafrik, Research Engineer.

"CMS IntelliCAD is solid product at a great price.
The interface is intuitive and anyone with prior CAD software experience can install it and be up-and-running within minutes.
Installation is a snap and friendly support staff make this a software product worth your consideration."
Karl Keip, Texas Hydraulics, Inc. IT Manager.

"You can safely buy any product from CMS as they are certainly prepared to help and support you in case you need it. They have proven to me a very professional and excellent behavior of business manner. I can strongly recommend them as a very good and serious supplier. Best regards to all at CMS from a happy and satisfied customer."
Tom Palle Hansen.

See Google Checkout End User reviews about CMS IntelliCAD experience:

CMS IntelliCAD End User Reviews >

Trial:

Freely download CMS IntelliCAD 6.6 PRO from http://intellicadms.com

Pricing:

CMS IntelliCAD 6.6 PRO Upgrade from any CAD Software, can be purchased for $149.95 / seat.

Buy directly from our online store at:

http://store.intellicadms.com

CMS IntelliCAD 5 stars customer review rating

March 8, 2010 - Bryant, Arkansas, USA. CMS, Inc. online store http://store.intellicadms.com uses Google Checkout™ to manage payments for all CMS IntelliCAD and CMS Software purchases.

At the fourth quarter of 2008, CMS has selected Google Checkout™ services due to the potential high end quality service and extreme security assurance. The integration done with our online store resulted in a much faster and reliable purchase process that is now available to all of our customers.

This purchase process is somehow different from what is considered "old way, simple, direct and easy". A customer does not require an user account to be able to purchase our products. Selecting a product and checking out is enough to checkout and prepare an order for payment. "How much simpler can it be?"

Credit Card Payment approval process usually is extremely fast. After payment, the customer is automatically redirected back to the store. At this point, a store user account has been automatically created and the customer is immediately able to browse his store account, retrieve is license information, download our software and receipt. Customer license information will be always securely stored.

Due to security reasons, CMS does not send any software license information to a customer email box.

Some foreign purchases may require some extra time to approve the credit card use. In some cases, it can take some extra time/minutes, or it can even be declined. Customer will always be notified by an email message.

Customer feedback has been extremely valuable to tune some of the store features. Due to the high level of integration with Google tools, Google Product Search is able to collect customer Google Checkout™ reviews regarding CMS purchasing process, and we are now extremely excited with the results made public by Google.

CMS has the highest 2010 seller average rating, 5/5.  And an overall average rating: 4.7 / 5 - Based on 55 reviews. Don't take our word for granted, CMS has NO INTERFERENCE whatsoever on customer reviews:

"I got what I paid for in a timely manner. Very happy with it."

"Excellent service and ongoing support !!"

"Excellent. Good back up support."

"I was able to activate my software within minutes of purchase. Thanks."

This confirms that Google Checkout™ was the right choice for our store and our CMS IntelliCAD customers.

Adjusting the Hatch Origin

By default, hatches are created starting from the drawings origin (0,0,0 of the active UCS). This often causes the hatch pattern becomes misaligned from the rest of the drawing. For example, suppose we have a box with 5x5 units and we need to place a simple horizontal hatch of 1 unit in order to have 5 strips of 1 unit each strip. Unless the box has been created at the 0,0,0 point or, at least, the Y coordinate of its base be multiple of 1, we will never achieve the desired result if we just place the hatch on that box.

The solution for this problem relies on the SNAPBASE system variable. The program's help says that this variable "Defines the xy location of the grid origin in the current viewport relative to the active UCS." and it is of type of a point.

If we set the SNAPBASE to one of the box's vertices and then apply the hatch, the hatch will be created starting from that vertice.

Here is an example of three boxes (5x5 units) with horizontal hatches:

Box 1 is created at drawing's origin, so the hatch will match the desired result.

Box 2 is created somewhere and hatch is applied without setting the SNAPBASE point. Note how the strips has different dimensions.

Box 3 is created somewhere (it stands in the same Y coordinate as Box 2) and the hatch is applied AFTER setting the SNAPBASE to the lower-left vertice.
